Paint bucket crusher Introduction

The paint bucket crusher is a new type of equipment designed for crushing paint buckets in metal crushers. On the basis of absorbing the advantages of various crushers, this series of paint bucket crushers of our company make full use of impact, shear, blow, and grinding. Wait for the theory to be carefully developed. When the paint bucket crusher is working, the materials can be sufficiently and effectively finely crushed in the crushing cavity. The paint bucket crusher has high output, low energy consumption, high efficiency, and uniform discharge of materials. The paint bucket crusher production line system is equipped with a dust removal device to reduce the pollution hazards such as dust, paint peels, and paper scraps generated during the production process to a lower level. The produced metal particles are of good quality and high density. The paint bucket crusher has the characteristics of Low noise, no pollution, simple operation and convenient maintenance. This machine is widely used for paint barrels, tin cans, paint barrels, pig iron filings, aluminum ash, metal magnesium, iron ore, small paint barrels, waste cans, lulu cans, beverage cans, beer cans, Red Bull cans, eight-treasure porridge cans , Heqizheng cans, metal bottles, cans, cola cans, paint cans, thin iron sheets, scrap iron slag, moon cake boxes, cans and other cans are broken into pellets, thereby reducing transportation costs and increasing scrap iron investment The speed of furnace iron making. It has high output, low energy consumption, high efficiency, uniform discharging, low noise, no pollution, simple operation and convenient maintenance when using this equipment. It is an ideal metal crushing equipment.

Album

Advantages

1. The ratio of molten steel produced to scrap steel is high;

2. The composition of each furnace of molten steel is stable;

3. The content of phosphorus in molten steel is low;

4. The sulfur content in molten steel is low;

5. When mixing with other scrap steel, the paint bucket ball can fill the gap and increase the feeding density;

6. When smelting, the number of feedings is reduced;

7. During smelting, electrode damage is reduced;

8. During smelting, the furnace is heated evenly;

9. The life of the refractory lining in the furnace is prolonged;

10. Air pollution is reduced during smelting;

11. During smelting, the technical operation is relatively easy;

12. The power consumption per ton of molten steel is reduced;

Working Principle

The crushing cavity of the paint bucket crusher is to support the rotor and the grate bar to realize the crushing of the material and to ensure that there is a large enough crushing cavity to fully crush the material; the object enters the crushing cavity of the paint bucket crusher under the influence of gravity. The degree of crushing of the materials is different. The first "nested crushing" is the first "nested crushing". After the materials are impacted again, they will be rebounded by the impact plate of the paint bucket crusher to the hammer striking area to be repeatedly crushed; continuously crushing the materials to improve the product The crushing quality is generally 10-20, and the highest can reach 50-60; after the material enters the crushing cavity, the garbage in the paint bucket is sorted by air selection during the crushing process, and the material after the paint bucket crusher crushes The composition is stable, the crushed materials are clean and beautiful, and there is no debris. It is a high-quality raw material for steelmaking. The equipment of Guangke Machinery Paint Bucket Crusher is reasonable in design and generous in appearance. The size of the feed inlet can be modified according to the needs of users, and it will never return materials and will not cause personal injury.

Parameter

model	Type 600	800 type	1000 type	Model 1300	1600 type	Model 1800
power	18.5-22	20-30	37-45	90-150	150-180	180-220
Yield	0.3-0.6	1-2	2-3	3-5	5-10	10-25
weight	2.5	3.7	4.4	4.5	twenty two	26
Host size	2.65x1.5x1.85	2.8x1.8x1.95	2.9x2.8x2.4	2.9x3x2.8	3.2x3.6x3.5	3.8x3.8x4.2
