Car shredder

Car shredder

The car shredder production line is mostly used in the recycling and processing of waste car machinery and the car smelting industry

InquireInquire

InquireInquire

Applicable materials : metal materials are fed into the shredding cavity from the feeding port through the conveyor belt; the motor drives the rotor through the industrial gear box; the meshing rotors are torn, squeezed, and bitten to shred the materials into small pieces; to achieve secondary processing Requirement size, or auxiliary equipment for convenient storage and transportation.

24-hour hotline:+86 15515585656

Get free quote

Car shredder Introduction

The car shredder production line is mostly used in the recycling and processing of waste car machinery and the car smelting industry. The car shredder produced by Guangke Machinery Co., Ltd. is a car shredder pulverizing system developed after years of research and practice combined with foreign technology. The car shredder is mainly composed of electrical parts and mechanical parts. The electrical part includes: motor and electric cabinet; the mechanical part includes: reducer, frame, rotor, bearing box, etc.

The car shredder has been widely used in the resource recycling industry, also known as the car shredder or the shearing machine. The working principle is to drive the shaft and the cutter through the gearbox through the high-power electric power to rotate against each other to achieve the squeeze of the material. , Shredding and shearing.

Album

Advantages

1. The volume occupied by the chips can be greatly reduced, and the chips can be fed continuously or intermittently;

2. The equipment has the advantages of large torque, high output, low noise, and wear resistance;

3. Guangke car shredder has the advantages of large crushing ratio, high production efficiency, and small discharge particle size;

4. The shredded metal particles are very clean, free of impurities and paint.

Working Principle

Suitable for shredding waste car shells, waste bicycles, waste motorcycles, car cabs, car doors, file cabinets, car sheet metal, safes, car slots, car bumpers, water tanks, waste steel, steel furniture and various Scrap metal. The output size can be adjusted according to user requirements.

At present, the domestic automobile production and sales have far surpassed other motor vehicles such as motorcycles. After these two or three decades of development, the disposal of scrapped automobiles is a headache, and the emergence of automobile shredders has solved it very well. The car shell is difficult to crack. In the past, scrapped cars were cut manually with an oxygen gun, and then processed after being cut with a hydraulic shearing machine. The car shredder has greatly saved labor and improved efficiency. It only needs to push the scrapped car into the shredder, and after ten minutes, it will be completely shredded and cut by the shredder. At present, the car shredder has been increasingly used. The more scrapped cars are used by dismantling companies.

1: Heavy movable knife with high crushing power. The knives are made of steel through forging production and processing, which is strong and has a long service life.

2: The fuselage is welded with high-strength steel plate, which can resist high torque, and the fuselage is very sturdy and durable.

3: Using a microcomputer (PC) automatic control, with start, stop, reverse and overload automatic reverse control functions;

4: The equipment has the characteristics of low speed, high torque, low noise, and dust can reach environmental protection standards.

5: Easy to adjust, low maintenance cost, economical and durable.

Parameter

model

2600

1900

1500

1200

1000

600


Spindle power (kw)

4-160*2

4-90*2

4-45*2

4-37*2

4-30*2

4-15*2


Spindle speed (r/min)

16-18

14-16

14-16

18-20

18-20

18-20


Capacity (t/h)

25-60

10-25

8-18

6-15

5-10

2-5


Conveyor power (kw)

4-3kw

4-3kw

4-3kw

none

none

none


Number of cutter heads (pieces)

40

40

30

28

30

26


Different materials, different number of teeth and blades, can be customized

Cutter diameter (mm)

Φ720

Φ560

Φ530

Φ372

Φ360

Φ260


Broken size (cm)

3-10

3-10

3-10

3-10

3-10

3-10


Silo size (mm)

2425*1400

2300*200

2000*2000

1400*1000

1200*1000

820*900


Dimensions (mm)

8200*4000*4300

8000*2500*2400

4000*1700*2400

3200*2000*1900

3000*2000*1900

2600*2000*1900


Weight(t)

36

15

12

6

5

2.5
