Position：Home>Product>Metal shredder series
The can shredder is small in size and convenient to move; manual operation is simple and safe; the built-in garbage bag is fixed with a lock, which is stable and not easy to slip, and the equipment is strong and durable.
2-60(T/H)
4-300(KW)
Applicable materials : waste cans, lulu cans, beverage cans, beer cans, Red Bull cans, eight-treasure porridge cans, Heqizheng cans, metal bottles, cans, cola cans, paint cans, waste thin iron sheets, scrap iron slag, moon cake boxes, cans Box etc.
24-hour hotline:+86 15515585656
The can shredder is a kind of solid waste reduction mechanical environmental shredder equipment, used cans, lulu cans, beverage cans, beer cans, Red Bull cans, eight-treasure porridge cans, and other cans, metal bottles, cans, cola cans, Paint buckets, thin iron sheets, scrap iron slag, moon cake boxes, cans and other cans are broken into clumps of particles, thereby reducing transportation costs and increasing the speed of scrap iron making.
The can shredder consists of a shredding mechanism, a support, a recovery box and a pull cart. The size of the equipment is determined by the size of the material and the amount of material handled. The inside of the can shredder is designed with a filter screen device. When the can shredder is working normally, the filter screen plays the role of separating materials and liquids, effectively recycling the liquid remaining on the bottle. For example, when the gasoline bottle is crushed, the residual gasoline can be effectively separated and recovered.
1. The design of this machine is reasonable, the body is welded with high-quality steel, and the frame is thick, which can resist high torque and is very strong.
2. It is fastened with high-strength screws, has a solid structure, and is durable. The equipment has the characteristics of high speed, large torque, low noise, and dust can reach environmental protection standards.
3. The design of the main engine is exquisite, and the shredded material adopts the separate design, which makes the output higher, easy to adjust, low maintenance cost, economical and durable.
4. The processed and broken pieces are uniform, soft milling shredding, low noise, low energy consumption, and uniform shredding. The thickness of the cutter and the number of claws can be changed according to different materials. Multiple screens can be replaced at the same time to meet different needs.
5. Heavy movable knife, high crushing efficiency, all cutting tools are made of alloy steel casting, strong and long service life. At the same time, it is equipped with knives of different materials, so that for different materials, the knives can be adjusted telescopically, and can be ground after being blunt. They can be used for many times and have a long life.
6. This machine has the advantages of excellent structure, beautiful appearance, easy operation, stable operation, low investment and high efficiency.
7. Equipped with an enlarged pulley to increase the inertia of the crusher, which can save energy and powerfully crush.
8. It adopts microcomputer (PLC) automatic control, and all contact control electrical appliances adopt high technology. Set up start, stop, reverse and overload automatic reverse control functions.
The can shredder adopts dual-shaft or single-shaft rotation at low speed, and uses a cutter head to cut, cut, tear and pull materials. The direct-connected worm gear motor is directly installed on the driving shaft of the shredder, and transmitted to the driven shaft through gear transmission, so that the movable knife of the driving shaft and the stationary cutter head on the housing form a relative movement. The spiral tooth cutter discs on the driving shaft are arranged in a staggered manner, so that after the material enters, it is simultaneously subjected to the effects of squeezing, tearing and shearing, so that the material can be shredded.
model | 2600 | 1900 | 1500 | 1200 | 1000 | 600 | |
Spindle power (kw) | 4-160*2 | 4-90*2 | 4-45*2 | 4-37*2 | 4-30*2 | 4-15*2 | |
Spindle speed (r/min) | 16-18 | 14-16 | 14-16 | 18-20 | 18-20 | 18-20 | |
Capacity (t/h) | 25-60 | 10-25 | 8-18 | 6-15 | 5-10 | 2-5 | |
Conveyor power (kw) | 4-3kw | 4-3kw | 4-3kw | none | none | none | |
Number of cutter heads (pieces) | 40 | 40 | 30 | 28 | 30 | 26 | |
Different materials, different number of teeth and blades, can be customized | |||||||
Cutter diameter (mm) | Φ720 | Φ560 | Φ530 | Φ372 | Φ360 | Φ260 | |
Broken size (cm) | 3-10 | 3-10 | 3-10 | 3-10 | 3-10 | 3-10 | |
Silo size (mm) | 2425*1400 | 2300*200 | 2000*2000 | 1400*1000 | 1200*1000 | 820*900 | |
Dimensions (mm) | 8200*4000*4300 | 8000*2500*2400 | 4000*1700*2400 | 3200*2000*1900 | 3000*2000*1900 | 2600*2000*1900 | |
Weight(t) | 36 | 15 | 12 | 6 | 5 | 2.5 | |
