The scrap iron shredder can shred all kinds of waste paint buckets, cans, pots, scrap iron sheets, aluminum profiles, copper rods, tubes, circuit boards and other light and thin materials. It is mainly used for briquetting, smelting, and tearing. The preliminary treatment of crushing and other industries.
0.5-10t/h
50-2000mm
Applicable materials : scrap steel, iron cans, paint buckets, color steel tiles, light and thin materials, car racks, old home appliances, car shells, etc.
24-hour hotline:+86 15515585656
Scrap iron shredder is a kind of shredder, is a machine used to shred scrap iron materials, and belongs to medium-sized metal shredder. It can shred used bicycles, motorcycles, refrigerators, washing machines, computer hard drives, motherboards, iron drums, aluminum aluminum cans, waste aluminum products, light bulbs, waste paint barrels, cans, beer bottle caps, etc. into ideal particles. Greatly facilitate transportation, reduce transportation costs and facilitate reprocessing.
The scrap iron shredder is used for crushing fragile metal materials such as pig iron powder, alloys, ferrosilicon powder, bottle caps, cans, circuit boards, and waste mobile phone batteries. Scrap iron shredder This machine can crush all kinds of scraps, and can be equipped with a magnetic roller to separate the mixed aluminum and iron scraps, and has the advantage of small shredder size. Scrap iron shredder This machine runs at a low speed and uses a cutter head to cut and tear the material. It has the advantages of large torque, high output, no noise, and wear resistance.
1. The design of this machine is reasonable, and the body is welded with high-quality steel.
2. Adopt high-strength screws to fasten, solid structure and durable.
3. The design of the main machine is exquisite, and the shredded material adopts a separate design to make the output higher.
4. The processed and broken pieces are uniform and the loss is small. Multiple screens can be replaced at the same time to meet different needs.
5. Equipped with knives of different materials at the same time, so that the knives can be adjusted telescopically for different materials, and can be ground after being blunt. They can be used for multiple times and have a long life.
6. This machine has the advantages of excellent structure, beautiful appearance, easy operation, stable operation, low investment and high efficiency.
7. Equipped with an enlarged pulley to increase the inertia of the crusher, which can save energy and powerfully crush.
1. The main body of the shredder
The main body of the equipment adopts high-quality steel plate welding to eliminate stress treatment/ overall machining to ensure the stability of the equipment under heavy load for a long time.
2. Bearings/seals
The bearing seat adopts a special split and easy disassembly type, which can quickly remove the movable knife, fixed knife, bearing and other parts, easy to maintain and replace the knife. The unique sealing structure effectively blocks the contact of broken objects and grease, and the liquid material can also protect the bearing. And gears, etc.
3. Movable knife/fixed knife
The movable knife material is made of special special alloy tool steel forging blanks, precision machining, multiple heat treatments and low temperature freezing heat treatment technology. The overall toughness and hardness are consistent and can be used repeatedly to ensure the cutting performance and service life. The fixed knife adopts special hook type installation to optimize the tool replacement function, so that the maintenance and replacement of the tool can be accelerated.
4. Knife shaft
Use high-strength and heavy-duty special steel to process and refine, more reasonably cooperate with the cutting tool to provide powerful power for cutting
model | 2600 | 1900 | 1500 | 1200 | 1000 | 600 | |
Spindle power (kw) | 4-160*2 | 4-90*2 | 4-45*2 | 4-37*2 | 4-30*2 | 4-15*2 | |
Spindle speed (r/min) | 16-18 | 14-16 | 14-16 | 18-20 | 18-20 | 18-20 | |
Capacity (t/h) | 25-60 | 10-25 | 8-18 | 6-15 | 5-10 | 2-5 | |
Conveyor power (kw) | 4-3kw | 4-3kw | 4-3kw | none | none | none | |
Number of cutter heads (pieces) | 40 | 40 | 30 | 28 | 30 | 26 | |
Different materials, different number of teeth and blades, can be customized | |||||||
Cutter diameter (mm) | Φ720 | Φ560 | Φ530 | Φ372 | Φ360 | Φ260 | |
Broken size (cm) | 3-10 | 3-10 | 3-10 | 3-10 | 3-10 | 3-10 | |
Silo size (mm) | 2425*1400 | 2300*200 | 2000*2000 | 1400*1000 | 1200*1000 | 820*900 | |
Dimensions (mm) | 8200*4000*4300 | 8000*2500*2400 | 4000*1700*2400 | 3200*2000*1900 | 3000*2000*1900 | 2600*2000*1900 | |
Weight(t) | 36 | 15 | 12 | 6 | 5 | 2.5 | |
